In StockWater Tank Radiator Core ASS'Y 561-03-81632 561-03-81631 for Komatsu Dump Truck HD785-7
For KomatsuRadiator

Radiator 561-03-81632 for Komatsu

OEM / REF: 561-03-81632SKU: pilotpart105237

Water Tank Radiator Core ASS'Y 561-03-81632 561-03-81631 for Komatsu Dump Truck HD785-7 is a Radiator replacement part indexed for Part Number and Komatsu Dump Truck HD785-7 Water Tank Radiator Core ASS'Y 561-03-81632 561-03-81631, with 3 application records on file. Match OEM part number 561-03-81632 and confirm fi...

Stock
In stock
Condition
New
Fitment
Komatsu HVAC Parts
Category
Radiator
  • Fitment support before you order
  • Worldwide delivery options

Radiator Description

This Radiator is indexed for Part Number; Komatsu Dump Truck HD785-7 Water Tank Radiator Core ASS'Y 561-03-81632 561-03-81631; Model: HD785-7 Specification: SIZE(mm):1530*445*125 Details: HD785-7 S/N 8832-UP (KAL Spec.) DUMP TRUCKS HD785-7 S/N 8393-UP (-40 deg C Spec.) DUMP TRUCKS HD785-7 S/N 8173-UP DUMP TRUCKS HD785-7 S/N 7001-8172 DUMP TRUCKS HD785-7 S/N 30430-UP (For New Caledonia) DUMP TRUCKS HD785-7 S/N 30001-UP DUMP TRUCKS HD785-7 S/N 30001-UP (KAL Spec.) DUMP TRUCKS HD785-7 S/N 30001-UP (-40 deg C Spec.) DUMP TRUCKS; Komatsu Komatsu Dump Truck HD785-7. Compare reference number 561-03-81632 against the label on your existing Komatsu component before ordering.

Additional cross references on file: 561-03-81631, HD785-7. If your machine plate shows a different number, submit a fitment inquiry with photos before checkout.

Applications

  • Part Number
  • Komatsu Dump Truck HD785-7 Water Tank Radiator Core ASS'Y 561-03-81632 561-03-81631
  • Model: HD785-7 Specification: SIZE(mm):1530*445*125 Details: HD785-7 S/N 8832-UP (KAL Spec.) DUMP TRUCKS HD785-7 S/N 8393-UP (-40 deg C Spec.) DUMP TRUCKS HD785-7 S/N 8173-UP DUMP TRUCKS HD785-7 S/N 7001-8172 DUMP TRUCKS HD785-7 S/N 30430-UP (For New Caledonia) DUMP TRUCKS HD785-7 S/N 30001-UP DUMP TRUCKS HD785-7 S/N 30001-UP (KAL Spec.) DUMP TRUCKS HD785-7 S/N 30001-UP (-40 deg C Spec.) DUMP TRUCKS
  • Komatsu Komatsu Dump Truck HD785-7

Specifications

Part Number561-03-81632,561-03-81631,5610381632,5610381631

Fitment Notes

Brand or application signal
Komatsu HVAC Parts
Product family
Radiator
System category
HVAC Parts > Cooling System Components > Radiator
Recommended verification
OEM number, engine model, serial number, old part photos, and dimensions.

Shipping & Returns

Availability
InStock
Shipping
Shipping quotes can be confirmed before payment for heavy or urgent orders.
Returns
Returns are easier when fitment is confirmed before ordering.
B2B support
Bulk, fleet, and repair-shop requests can be handled through the inquiry form.

Frequently Asked Questions

How do I confirm this part fits my machine?

Match the OEM or reference number first, then verify machine model, engine model, serial number, connector layout, mounting points, and old part photos.

Can I order if my part number is not listed?

Yes. Send the old part number, machine plate, and photos through the fitment inquiry form. Support can review possible replacements or alternatives.

Is this an OEM part?

Products are indexed as replacement parts unless explicitly marked otherwise. Always compare reference numbers and confirm fitment before purchase.
